Product Summary
The HEF4044B is a quad R/S latch with 3-state outputs, with a common output enableinput (OE). Each latch has an active LOW set input (1Sto4S), an active LOW reset input(1R to 4R) and an active HIGH 3-state output (1Q to 4Q).
Features
(1)Fully static operation; (2)5 V, 10 V, and 15 V parametric ratings; (3)Standardized symmetrical output characteristics; (4)Operates across the full industrial temperature range:40℃ to +85℃; (5)Complies with JEDEC standard JESD 13-B; (6)ESD protection:N HBM JESD22-A114E exceeds 2000V;N MM JESD22-A115-A exceeds 200 V
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127255013452.jpg">
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HEF4044BT,652 |
NXP Semiconductors |
Latches QUAD R/S LATCH 3ST |
Data Sheet |
|
|
||||||||||||
|
HEF4044BT,653 |
NXP Semiconductors |
Latches QUAD R/S LATCH W/3-STATE OUTPT |
Data Sheet |
|
|
||||||||||||
