Product Summary
The CD40106B Hex Schmitt Trigger is a monolithic complementary MOS (CMOS) integrated circuit constructed with N
and P-channel enhancement transistors. The positive and negative-going threshold voltages, VTa and VTb, show low
variation with respect to temperature (typ 0.0005V/§C at VDD e 10V), and hysteresis, VTa b VTb t 0.2 VDD is
guaranteed.All inputs are protected from damage due to static discharge by diode clamps to VDD and VSS
Parametrics
Absolute Maximum Ratings:
- DC Supply Voltage (VDD):-0.5 to +18 VDC
- Input Voltage (VIN):-0.5 to VDD+0.5 VDC
- Storage Temperature Range (TS):-65℃ to +150℃
- Power Dissipation (PD),Dual-In-Line:700 mW;Small Outline:500 mW
- Lead Temperature (TL),(Soldering, 10 seconds):260℃
Features
- Wide supply voltage range: 3V to 15V
- High noise immunity: 0.7 VDD (typ.)
- Low power: Fan out of 2 driving 74L
- TTL compatibility or 1 driving 74LS
- Hysteresis:0.4 VDD (typ.);0.2 VDD guaranteed
- Equivalent to MM54C14/MM74C14
- Equivalent to MC14584B
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 CD40106BCN |
Fairchild Semiconductor |
Inverters Hex Schmitt Trigger |
Data Sheet |
Negotiable |
|
||||
|
CD40106BCN_Q |
Fairchild Semiconductor |
Inverters Hex Schmitt Trigger |
Data Sheet |
Negotiable |
|
||||
