Product Summary
Parametrics
Selected Electrical Specifications:
GLOBAL CHARACTERISTICS:
(1)Supply Voltage:2.7V to 3.6V; (2)Supply Current (CPU active):Clock = 25 MHz:18mA;Clock = 1 MHz:0.7mA;Clock = 32 kHz,VDD Monitor Enabled:20μA; (3)Supply Current(shutdown),Oscillator not running; VDD MonitorDisabled:0.1μA; (4)Clock Frequency Range,DC:25MHz
Features
(1)Analog PeripheralsTwo 16-Bit ADCs; (2)On-Chip JTAG Debug & Boundary Scan; (3)Supply Voltage: 2.7 to 3.6 V; (4)High-Speed 8051 μC Core; (5)Memory: 4352 bytes data RAM; 64 kB Flash; in-system programmable in 1024-byte sectors (1024 bytesare reserved); External parallel data memory interface; (6)CAN Bus 2.0B:32 message objects;"Mailbox" implementation only interrupts CPU when needed; (7)Digital Peripherals; (8)Clock Sources; (9)100-Pin TQFP,Temperature Range: -40℃ to +85℃
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127230376912.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
C8051F060 |
Silicon Labs |
8-bit Microcontrollers (MCU) 64KB 16ADC |
Data Sheet |
Negotiable |
|
|||||||||||
C8051F060DK |
Silicon Labs |
Development Boards & Kits - 8051 MCU DEVELOPMENT KIT W/ US POWER SUPPLY |
Data Sheet |
|
|
|||||||||||
C8051F060-GQ |
Silicon Labs |
8-bit Microcontrollers (MCU) 64KB 16ADC CAN 100P MCU |
Data Sheet |
|
|
|||||||||||
C8051F060-GQR |
Silicon Labs |
8-bit Microcontrollers (MCU) 64KB 16ADC CAN 100P Tape and Reel |
Data Sheet |
|
|
|||||||||||
C8051F060R |
Silicon Labs |
8-bit Microcontrollers (MCU) ADC 16/100Pin |
Data Sheet |
Negotiable |
|
|||||||||||
C8051F060DK-U |
DEV KIT FOR F060/F062/F063 |
Data Sheet |
Negotiable |
|
||||||||||||
C8051F060-TB |
Silicon Labs |
Sockets & Adapters for C8051F060 |
Data Sheet |
|
|
