Product Summary

The AO4407A uses advanced trench technology toprovide excellent RDS(ON), and ultra-low low gate chargewith a 25V gate rating. This device is suitable for use asa load switch or in PWM applications. Standard ProductAO4407A is Pb-free (meets ROHS & Sony 259specifications).

Parametrics

Absolute Maximum Ratings(TA=25°C unless otherwise noted):
(1)Drain-Source Voltage:-30V; (2)Gate-Source Voltage:±25V; (3)Continuous Drain Current:(TA=25℃):-12A to -9.2A;(TA=70℃):-10A to -7.4A; (4)Pulsed Drain Current:-60A; (5)Avalanche Current:26A; (6)Repetitive avalanche energy(L=0.3mH):101mJ; (7)Power Dissipation:(TA=25℃):1.7W to 3.1W;(TA=70℃):1.1W to 2.0W; (8)Junction and Storage Temperature Range:-55℃ to 150℃

Features

VDS = -30
VID = -12A (VGS = -10V)
RDS(ON) < 11m? (VGS = -20V)
RDS(ON) < 13m? (VGS = -10V)
RDS(ON) < 38m? (VGS = -10V)
