Product Summary
Parametrics
ABSOLUTE MAXIMUM RATINGS1:(1)VCC(DC supply voltage):-0.5 to +4.6V; (2)IIK(DC input diode current,VI < 0):-50mA; (3)VI(DC input voltage3):–0.5 to +7.0V; (4)IOK(DC output diode current,VO < 0):-50mA; (5)VOUT(DC output voltage3,Output in Off or High state):-0.5 to +7.0V; (6)IOUT(DC output current):Output in High state:-32mA;Output in Low state:64mA; (7)Tstg(Storage temperature range):-65℃ to 150℃
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201271245657289.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
74LVT32PW,112 |
IC QUAD 2IN OR GATE 3.3V 14TSSOP |
Data Sheet |
|
|
||||||||||||||||||||
74LVT32PW,118 |
IC GATE OR 3.3V QUAD 2IN 14TSSOP |
Data Sheet |
|
|
