Product Summary

The SN74F08 contains four independent 2-inputAND gates. It performs the Boolean functionsY = A*B or Y = A + B in positive logic.It is characterized for operation from0°C to 70°C.

Parametrics

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)?:(1)Supply voltage range(Vcc):-0.5 V to 7 V; (2)Input voltage range:-1.2 V to 7 V; (3)Input current range:-30 mA to 5mA; (4)Voltage range applied to any output in the high state:-0.5 V to VCC; (5)Current into any output in the low state:40 mA; (6)Operating free-air temperature range:0℃ to 70℃; (7)Storage temperature range:-65℃ to 150℃

Features

1.Package Options Include Plastic
2.Small-Outline Packages and StandardPlastic 300-mil DIPs

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201271243154374.jpg">
