Product Summary

Parametrics

Absolute Maximum Ratings TC=25℃ unless otherwise noted:
(1)Collector-Base Voltage:-100V; (2)Collector-Emitter Voltage :-100V; (3)Emitter-Base Voltage:-5V; (4)Collector Current (DC):-6V; (5)Collector Current (Pulse):-10A; (6)Base Current:-2A; (7)Collector Dissipation (TC=25℃):65℃; (8)Junction Temperature:150℃; (9)Storage Temperature:-65℃ to 150℃

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127244620235.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TIP42C
TIP42C

STMicroelectronics

Transistors Bipolar (BJT) PNP Gen Pur Power

Data Sheet

0-1: $0.27
1-10: $0.26
10-100: $0.23
100-250: $0.22
TIP42C-BP
TIP42C-BP

Micro Commercial Components (MCC)

Transistors Bipolar (BJT) PNP -100V -6A 65W

Data Sheet

0-1000: $0.34
TIP42CG
TIP42CG

ON Semiconductor

Transistors Bipolar (BJT) 6A 100V 65W PNP

Data Sheet

0-1: $0.39
1-25: $0.34
25-100: $0.26
100-500: $0.22
TIP42CN
TIP42CN

STMicroelectronics

Transistors Bipolar (BJT) PNP 100 Volt 6 Amp

Data Sheet

Negotiable
TIP42CPTU
TIP42CPTU

Fairchild Semiconductor

Transistors Bipolar (BJT)

Data Sheet

Negotiable
TIP42C-S
TIP42C-S

Bourns

Transistors Bipolar (BJT) 100V 6A PNP

Data Sheet

0-5960: $0.40
5960-15000: $0.35
TIP42CTU
TIP42CTU

Fairchild Semiconductor

Transistors Bipolar (BJT) PNP Epitaxial Sil

Data Sheet

0-1: $0.41
1-25: $0.30
25-100: $0.26
100-250: $0.23
TIP42CE3
TIP42CE3

Other


Data Sheet

Negotiable
