Product Summary
The TEA2025B/D is a monolithic integrated circuitin 12+2+2 Powerdip and 12+4+4 SO, intended foruse as dual or bridge power audio amplifier port-able radio cassette players.
Parametrics
ABSOLUTE MAXIMUM RATINGS:
(1)Supply Voltage:15V; (2)Ouput Peak Current:1.5A; (3)Junction Temperature:150℃; (4)Storage Temperature:150℃
Features
(1)DUAL OR BRIDGE CONNECTION MODES; (2)FEW EXTERNAL COMPONENTS; (3)SUPPLY VOLTAGE DOWN TO 3V; (4)HIGH CHANNEL SEPARATION; (5)VERY LOW SWITCH ON/OFF NOISE; (6)MAX GAIN OF 45dB WITH ADJUST EXTER-NAL RESISTOR; (7)SOFT CLIPPING; (8)THERMAL PROTECTION; (9)3V < VCC < 15V; (10)P= 2*1W, VCC = 6V, RL =4Ω; (11)P= 2* 2.3W, VCC = 9V, RL =4Ω; (12)P= 2*0.1W, VCC = 3V, RL =4Ω
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201272445944698.jpg">
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TEA2025B |
STMicroelectronics |
Audio Amplifiers Stereo Audio Amp |
Data Sheet |
|
|
||||||||||||
