Product Summary

The driver is designed for up to 60 mA of sink or source current. The driver features positive and negative currentlimiting and thermal shutdown for protection from line-fault conditions.Thermal shutdown is designed to occurat a junction temperature of approximately 150℃. The receiver features a minimum input impedance of 12 kΩ,an input sensitivity of±200 mV, and a typical input hysteresis of 50 mV.

Parametrics

absolute maximum ratings:(1)Supply voltage, VCC (see Note 1):7V; (2)Voltage range at any bus terminal:–10 V to 15 V; (3)Enable input voltage, VI:5.5 V; (4)Package thermal impedance,θJA: D package:97℃/W,P package:85℃/W,PS package:95℃/W; (5)Operating virtual junction temperature, TJ:150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds:260℃; (7)Storage temperature range, Tstg:–65℃ to 150℃

Features

(1)Bidirectional Transceivers; (2)Meet or Exceed the Requirements of ANSIStandards TIA/EIA-422-B and TIA/EIA-485-Aand ITU Recommendations V.11 and X.2; (3)Designed for Multipoint Transmission on Long Bus Lines in Noisy Environments; (4)3-State Driver and Receiver Outputs; (5)Individual Driver and Receiver Enables; (6)Wide Positive and Negative Input/Output Bus Voltage Ranges; (7)Driver Output Capability:±60 mA Max; (8)Thermal Shutdown Protection; (9)Driver Positive and Negative CurrentLimiting; (10)Receiver Input Impedance:12 kΩMin; (11)Receiver Input Sensitivity:±200 mV; (12)Receiver Input Hysteresis:50 mV Typ; (13)Operate From Single 5-V Supply

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127223213964.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN75176BP
SN75176BP
Texas Instruments
Buffers & Line Drivers Bus Diff
Data Sheet
0-1: $0.34
1-25: $0.30
25-100: $0.23
100-250: $0.23
SN75176BPE4
SN75176BPE4
Texas Instruments
Buffers & Line Drivers Differential Bus Transceiver
Data Sheet
0-1: $0.47
1-25: $0.37
25-100: $0.32
100-250: $0.28
SN75176BPSRG4
SN75176BPSRG4
Texas Instruments
Buffers & Line Drivers Differential Bus Transceiver
Data Sheet
0-1: $0.55
1-25: $0.42
25-100: $0.37
100-250: $0.32
SN75176BPSR
SN75176BPSR
Texas Instruments
Buffers & Line Drivers Differential Bus Transceiver
Data Sheet
0-1: $0.55
1-25: $0.42
25-100: $0.37
100-250: $0.32
