HCPL-7840-500E

Parametrics

Absolute Maximum Ratings:


  1. Storage Temperature:-55 to 125℃
  2. Ambient Operating Temperature:-40 to 8℃
  3. Supply Voltages, VDD1, VDD2:0 to 5.5 V
  4. Steady-State Input Voltage, VIN+, VIN-:-2.0  to VDD1 +0.5 V ;2 Second Transient Input Voltage: -6.0V
  5. Output Voltages, VOUT+, VOUT-:-0.5   to VDD2 +0.5 V
  6. Lead Solder Temperature TLS:260℃


Features

1.High Common Mode Rejection (CMR): 15 kV/μs at VCM = 1000 V
2.5% Gain Tolerance
3. 0.1% Nonlinearity
4.Low Offset Voltage and Offset Temperature Coefficient
5.100 kHz Bandwidth
6.Performance Specified Over -40℃ to 85℃ Temperature Range
7.Recognized Under UL 1577 and CSA Approved for Dielectric Withstand Proof Test Voltage of 2500 Vac, 1 Minute
8.Standard 8-Pin DIP Package
