Product Summary

The AD7943, AD7945 and AD7948 are fast 12-bit multiplying DACs that operate from a single +5 V supply (Normal Mode) and a single +3.3 V to +5 V supply (Biased Mode). The AD7943 has a serial interface, the AD7945 has a 12-bit parallel interface, and the AD7948 has an 8-bit byte interface. They will replace the industry-standard AD7543, AD7545 and AD7548 in many applications, and they offer superior speed and power
consumption performance.

Parametrics

ABSOLUTE MAXIMUM RATINGS:
(1)VDD to DGND:-0.3 V to +6 V; (2)IOUT1 to DGND:-0.3 V to VDD + 0.3 V; (3)IOUT2 to DGND:-0.3 V to VDD + 0.3 V; (4)AGND to DGND:-0.3 V to VDD + 0.3 V; (5)Digital Input Voltage to DGND:-0.3 V to VDD + 0.3 V; (6)VRFB, VREF to DGND:±15 V; (7)Input Current to Any Pin Except Supplies:±10 mA; (8)Operating Temperature Range:Industrial (A, B Versions):-40℃ to +85℃;Extended (T Version):-55℃ to +125℃; (9)Storage Temperature Range:-65℃ to +150℃; (10)Junction Temperature:+150℃; (11)DIP Package, Power Dissipation:670 mW; (12)qJA Thermal Impedance:116℃/W; (13)Lead Temperature, Soldering, (10 sec):+260℃; (14)SOP Package, Power Dissipation:450 mW; (15)qJA Thermal Impedance:75/W; (16)Lead Temperature, Soldering:Vapor Phase (60 sec):+215℃;Infrared (15 sec):+220℃; (17)SSOP Package, Power Dissipation:875 mW; (18)qJA Thermal Impedance:132℃/W; (19)Lead Temperature, Soldering:Vapor Phase (60 sec):+215℃;Infrared (15 sec):+220℃

Features

(1)12-Bit Multiplying DACs; (2)Guaranteed Specifications with +3.3 V/+5 V Supply; (3)0.5 LSBs INL and DNL; (4)Low Power: 5 μW typ; (5)Fast Interface:40 ns Strobe Pulsewidth (AD7943);40 ns Write Pulsewidth (AD7945, AD7948); (6)Low Glitch: 60 nV-s with Amplifier Connected; (7)Fast Settling: 600 ns to 0.01% with AD843

Diagrams

<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127231295398.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD7943BRZ
AD7943BRZ

IC DAC 12BIT MULT SRL 16SOIC
Data Sheet
0-1: $5.54
1-10: $4.98
10-100: $4.10
100-250: $3.76
250-500: $3.43
500-1000: $2.99
1000-2500: $2.95
AD7943BRZ-REEL
AD7943BRZ-REEL

IC DAC 12BIT MULT SRL 16SOIC
Data Sheet
0-1000: $2.99
