Product Summary

The 74LX1G08 is a low voltage CMOS SINGLE 2-INPUT AND GATE fabricated with sub-micron silicon gate and double-layer metal wiring C 2MOS tecnology.It is ideal for 1.65 to 5.5 VCC operations and low power and low noise applications. The internal circuit is composed of 3 stages including buffer
output, which provide high noise immunity and stable output.

Parametrics

ABSOLUTE MAXIMUM RATINGS:

  1. VCC,Supply Voltage: -0.5 to +7.0 V
  2. VI, DC Input Voltage: -0.5 to +7.0 V
  3. VO,DC Output Voltage (VCC = 0V): -0.5 to +7.0 V
  4. VO,DC Output Voltage (High or Low State):-0.5 to VCC + 0.5 V
  5. I IK,DC Input Diode Current:- 50mA
  6. IOK,DC Output Diode Current:- 50 mA
  7. IO,DC Output Current :± 50 mA
  8. ICC or IGND, DC VCC or Ground Current per Supply Pin: ± 50 mA
  9. Tstg, Storage Temperature: -65 to +150℃
  10. TL,Lead Temperature (10 sec) :300℃


Features

(1)5V TOLERANT INPUTS;

(2)HIGH SPEED: tPD = 4.5ns (MAX.) at VCC = 3V;

(3)LOW POWER DISSIPATION:Icc = 1μA (MAX.) at TA = 25℃;

(4)POWER DOWN PROTECTION ON INPUTS AND OUTPUTS;

(5)SYMMETRICAL OUTPUT IMPEDANCE:|IoH| = Iol= 24mA (MIN) at VCC = 3V;

(6)BALANCED PROPAGATION DELAYS:tPLH= tPHL;

(7)OPERATING VOLTAGE RANGE:Voo(OPR) = 1.65V to 5.5V(1.2V Data Retention);

(8)IMPROVED LATCH-UP IMMUNITY

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74LX1G08CTR
74LX1G08CTR
STMicroelectronics
Gates (AND / NAND / OR / NOR) Single 2-Input AND
Data Sheet
0-1: $0.32
1-10: $0.23
10-100: $0.14
100-250: $0.10
