Product Summary

The 74HC/HCT32 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL(LSTTL). They are specified in compliance with JEDEC
standard no. 7A.The 74HC/HCT32 provide the 2-input OR function

Parametrics

QUICK REFERENCE DATA
GND = 0 V; Tamb=25℃; tr=tf=6 ns:

  1. tPHL/ tPLH ,propagation delay nA, nB to nY, CL = 15 pF; Vcc=5 V:6ns
  2. CI,input capacitance :3.5pF
  3. CPD, power dissipation capacitance per gate:16pF

Features

  1. Output capability: standard
  2. Icc category: SSI

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74HC32D,652
74HC32D,652
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-IN OR GATE
Data Sheet
0-1: $0.05
1-25: $0.05
25-100: $0.05
100-250: $0.04
74HC32D,653
74HC32D,653
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT OR GATE
Data Sheet
0-1: $0.05
1-25: $0.05
25-100: $0.05
100-250: $0.04
74HC32DB,112
74HC32DB,112
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT OR GATE
Data Sheet
0-1: $0.13
1-25: $0.11
25-100: $0.11
100-250: $0.10
74HC32DB,118
74HC32DB,118
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT OR GATE
Data Sheet
0-1: $0.29
1-25: $0.25
25-100: $0.21
100-250: $0.19
74HC32DR2G
74HC32DR2G

IC GATE OR QUAD 2INPUT 14-SOIC
Data Sheet
0-1: $0.29
1-10: $0.21
10-25: $0.17
25-100: $0.14
100-250: $0.10
250-500: $0.08
500-1000: $0.06
74HC32DTR2G
74HC32DTR2G

IC GATE OR QUAD 2INPUT 14-TSSOP
Data Sheet
Negotiable
