Product Summary

Fifth Generation HEXFETs from International Rectifier utilize advanced processing techniques to achieve extremely low

on-resistance per silicon area.

Parametrics

Absolute Maximum Ratings(TA=25℃ Unless otherwise noted)

  1. Drain-Source Voltage:-30 to +30V
  2. Gate-source Voltage:±20V
  3. Continuous Drain Current, VGS @Ta=25℃:-5.3 to 7.3A
  4. Continuous Drain Current, VGS @Ta=70℃:-4.2 to 5.9A
  5. Pulsed Drain Current:-30 to +30A
  6. Continuous Drain Current(Diode conduction)-2.5 to 2.5A
  7. Maximum power dissipation,TA=25℃:2.5W;TA=70℃:1.6W
  8. Single Pulse Avalanche Energy:82 to 140mJ
  9. Avalanche Current:-2.8 to 40A
  10. Repetitive Avalanche Energy:0.20mJ
  11. Peak Diode Recovery dv/dt:-2.2 to 3.8V/ns
  12. Operating Junction and Storage Temperature Range:-55 to+150℃


Features

  1. Generation V Technology
  2. Ultra Low On-Resistance
  3. Complimentary Half Bridge
  4. Surface Mount
  5. Fully Avalanche Rated
