Product Summary

Applications：
1.Switching regulators
2.UPS (Uninterruptible Power Supply)
3.DC-DC converters

Parametrics

Absolute maximum ratings (Tc=25℃  unless otherwise specified)：

(1)Drain-source voltage :VDS=150V;VDSX=120V;

(2)Continuous drain current:±57A;

(3)Pulsed  drain  current:±228A;

(4)Gate-source  voltage:±30V;

(5)Non-repetitive Avalanche current:57A;

(6)Maximum Avalanche Energy:272.5mJ;

(7)Maximum Drain-Source dV/dt:20kV/μs;

(8)Peak Diode Recovery dV/dt:5kV/μs;

(9)Max. power dissipation:Ta=25℃,2.02W;Tc=25℃, 270W;

(10)Operating  and  storage:+150℃;

(11)temperature  range:-55~+150℃

Features

(1)High speed switching;

(2)Low on-resistance;

(3)No secondary breadown;

(4)Low driving power;

(5)Avalanche-proof

Diagrams
