Product Summary
These octal bus transceivers are designed for asynchronous two-way communication between data buses. Thecontrol-function implementation minimizes external timing requirements.The devices allow data transmission from the A bus to the B bus or from the B bus to the A bus, depending uponthe logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable thedevice so that the buses are effectively isolated.
Parametrics
Absolute maximum ratings over operating free-air temperature range: (1)Supply voltage, VCC:7V; (2)Input voltage, VI: All inputs:7V;I/O ports:5.5V; (3)Package thermal impedance,θJA (see Note 1): DW package:58℃/W;N package:69℃/W;NS package:60℃/W; (4)Storage temperature range:–65℃ to 150℃
Features
(1)4.5-V to 5.5-V VCC Operation; (2)Max tpd of 5.5 ns at 5 V; (3)3-State Outputs Drive Bus Lines Directly; (4)pnp Inputs Reduce dc Loading
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/2012723165994.jpg">
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74AS245NSR |
Texas Instruments |
Bus Transceivers Octal Bus Trnscvrs With 3-State Outputs |
Data Sheet |
|
|
||||||||||
|
SN74AS245NSRE4 |
Texas Instruments |
Bus Transceivers Octal Bus Trnscvrs With 3-State Outputs |
Data Sheet |
|
|
||||||||||
|
SN74AS245NSRG4 |
Texas Instruments |
Bus Transceivers Octal Bus Trancvrs |
Data Sheet |
|
|
||||||||||
