MAXIMUM RATINGS:(1)DC Supply Voltage (Referenced to GND):-0.5 to+7.0V; (2)DC Input Voltage (Referenced to GND):-0.5 toVCC +0.5V; (3)DC Output Voltage (Referenced to GND):-0.5 toVCC +0.5VDC Input Current, per Pin:±20mA; (4)DC Output Sink/Source Current, per Pin:±50mA; (5)DC VCC or GND Current per Output Pin:±50mA; (6)Storage TemperatureTstg:-65℃ to+150℃
Features
(1)Outputs Source/Sink 24 mA; (2)′ACT02 Has TTL Compatible Inputs; (3)Pb-Free Packages are Available
