Product Summary

The DAC8043A is an improved high accuracy 12-bit multiplying digital-to-analog converter in space-saving 8-lead packages.
Featuring serial input, double buffering and excellent analog performance, the DAC8043A is ideal for applications where PC
board space is at a premium. Improved linearity and gain error performance permit reduced parts count through the elimination of trimming components.

Separate input clock and load DAC control lines allow full user control of data loading and analog output.

Parametrics

ABSOLUTE MAXIMUM RATINGS:

  1. VDD to GND:–0.3 V, +8 V
  2. VREF to GND:±18 V
  3. RFB to GND:±18 V
  4. Logic Inputs to GND:–0.3 V, VDD + 0.3 V
  5. VIOUT to GND: –0.3 V, VDD + 0.3 V
  6. IOUT Short Circuit to GND:50 mA
  7. Package Power Dissipation:(TJmax – TA)/θJA
  8. Thermal Resistance θJA
   8-Lead Plastic DIP Package (N-8):103/W
    8-Lead SOIC Package (SO-8):158/W
    TSSOP-8 Package (RU-8):240/W
9.Maximum Junction Temperature (TJ max) :+150
10.Operating Temperature Range:-40 to +85
11.Storage Temperature Range:-65℃ to +150
12.Lead Temperature (Soldering, 10 sec):+300


Features

  1. Compact SO-8 and TSSOP Packages
  2. True 12-Bit Accuracy
  3. +5 V Operation @ <10 mA
  4. Fast  3-Wire Serial Input
  5. Fast 1 ms Settling Time
  6. 2.4 MHz 4-Quadrant Multiply BW
  7. Pin-for-Pin Upgrade for DAC8043
  8. Standard and Rotated Pinout

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DAC8043FP
DAC8043FP


IC DAC 12BIT MULTIPLY CMOS 8-DIP

Data Sheet

0-50: $8.71
DAC8043FPZ
DAC8043FPZ


IC DAC 12BIT MULTIPLY CMOS 8-DIP

Data Sheet

0-1: $8.96
1-10: $8.14
10-25: $7.53
25-100: $6.92
100-250: $6.31
250-500: $5.90
500-1000: $5.43
