Product Summary

The AD8561 is a single 7 ns comparator with separate input and output sections. Separate supplies enable the input stage to be
operated from ±5 V dual supplies and +5 V single supplies.

Parametrics

ABSOLUTE MAXIMUM RATINGS:

  1. Total Analog Supply Voltage:+14 V
  2. Digital Supply Voltage:+14 V
  3. Analog Positive Supply–Digital Positive Supply:-600 mV
  4. Input Voltage:±7 V
  5. Differential Input Voltage :±8 V
  6. Output Short-Circuit Duration to GND:Indefinite
  7. Storage Temperature Range,N, R, RU Package :-65℃ to +150℃
  8. Operating Temperature Range:-40℃ to +85℃
  9. Junction Temperature Range,N, R, RU Package:-65℃ to +150℃
  10. Lead Temperature Range (Soldering, 10 sec):+300℃


Features

  1. 7 ns Propagation Delay at 5 V
  2. Single Supply Operation: 3 V to 10 V
  3. Low Power
  4. Latch Function

Diagrams
