Product Summary

The AD574A is a complete 12-bit successive-approximation analog-to-digital converter with 3-state output buffer circuitry for direct interface to an 8- or 16-bit microprocessor bus. A high
precision voltage reference and clock are included on-chip, and the circuit guarantees full-rated performance without external circuitry or clock signals.

Parametrics

ABSOLUTE MAXIMUM RATINGS:

  1. VCC to Digital Common:0 V to +16.5 V
  2. VEE to Digital Common:0 V to -16.5 V
  3. VLOGIC to Digital Common:0 V to +7 V
  4. Analog Common to Digital Common:±1 V
  5. Control Inputs (CE, CS, AO 12/8, R/C) to Digital Common:-0.5 V to VLOGIC + 0.5 V
  6. Analog Inputs (REF IN, BIP OFF, 10 VIN) to Analog Common:VEE to VCC
  7. 20 VIN to Analog Common:±24 V
  8. REF OUT:Indefinite Short to Common:Momentary Short to VCC
  9. Chip Temperature:175℃
  10. Power Dissipation:825 mW
  11. Lead Temperature (Soldering, 10 sec): +300℃
  12. Storage Temperature (Ceramic):-65℃ to +150℃;(Plastic):-25℃ to +100℃


Features

  1. Complete 12-Bit A/D Converter with Reference and Clock
  2. 8- and 16-Bit Microprocessor Bus Interface
  3. Guaranteed Linearity Over Temperature:0℃ to +70℃
  4. No Missing Codes Over Temperature
  5. 35 μs Maximum Conversion Time
  6. Buried Zener Reference for Long-Term Stability and Low Gain T.C. 10 ppm/8C max AD574AL;12.5 ppm/8C max AD574AU
  7. Ceramic DIP, Plastic DIP or PLCC Package
  8. Available in Higher Speed, Pinout-Compatible Versions (15 μs AD674B, 80 μs AD774B; 10 μs (with SHA) AD1674)
  9. Available in Versions Compliant with MIL-STD-883 and JAN QPL

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD574AJN
AD574AJN

IC ADC 12BIT W/REF 28-DIP
Data Sheet
0-13: $24.56
AD574AJNZ
AD574AJNZ

IC ADC 12BIT W/REF 28-DIP
Data Sheet
0-1: $22.09
1-10: $20.66
10-100: $17.91
100-250: $16.72
250-500: $15.92
