Product Summary
P-Channel MOS FET High Speed Power Switching
Parametrics
Absolute Maximum Ratings (Ta = 25℃):
(1)Drain to source voltage:-30V;
(2)Gate to source voltage:±20V;
(3)Drain current:-2A;
(4)Drain peak current:-4A;
(5)Body to drain diode reverse drain current:-2A;
(6)Channel dissipation:1W;
(7)Channel temperature:150℃;
(8)Storage temperature:-55℃ to +150℃
Features
(1)Low on-resistance,RDS(on)=0.18Ω typ. (at VGS=–10V, ID=–1A);
(2)Low drive current;
(3)High speed switching;
(4)4V gate drive devices
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 2SJ484 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
|
2SJ400 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
2SJ401 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
2SJ401(Q) |
|
MOSFET P-CH 60V 20A TO-220FL |
Data Sheet |
|
|
||||||
|
2SJ401(TE24L,Q) |
Toshiba |
MOSFET MOSFET P-Ch 60V 20A Rdson=0.045Ohm |
Data Sheet |
Negotiable |
|
||||||
|
2SJ402(Q) |
|
MOSFET P-CH 60V 30A TO-220FL |
Data Sheet |
|
|
||||||
|
2SJ403 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
