Product Summary

APPLICATION:
SMPS, DC-DC Converter, battery charger, power
supply of printer, copier, HDD, FDD, TV, VCR, personal computer etc

Parametrics

MAXIMUM RATINGS (Tc = 25℃):

  1. VDSS,Drain-source voltage,VGS=0V:450V
  2. VGSS,Gate-source voltage,VDS = 0V:±30V
  3. ID,Drain current:14A
  4. IDM,Drain current (Pulsed):42A
  5. PD,Maximum power dissipation:150W
  6. Tch,Channel temperature:-55 to+150℃
  7. Tstg,Storage temperature:-55 to+150℃
  8. Weight,Typical value:1.2g

Features

  1. VDSS:450V
  2. DS (ON) (MAX):0.52Ω
  3. ID:14A

Diagrams
