AT24C64AN-PU2.7

Two-wire Serial EEPROM 32K (4096 x 8) 64K (8192 x 8)

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.00~13.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $8.00~13.00

PartNumber:: AT24C64AN-PU2.7

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kaisy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-17

From Other Seller

Part Number:AT24C64AN-PU2.7
US $8.00 - 13.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C32A/64A provides 32,768/65,536 bits of serial electrically erasable andprogrammable read only memory (EEPROM) organized as 4096/8192 words of 8 bitseach. The device’s cascadable feature allows up to 8 devices to share a common two-wire bus. The device is optimized for use in many industrial and commercial applica-tions where low power and low voltage operation are essential. The AT24C32A/64A isavailable in space saving 8-lead JEDEC PDIP, 8-lead JEDEC SOIC, 8-lead EIAJSOIC, 8-lead Mini-MAP (MLP 2x3) and 8-lead TSSOP packages and is accessed viaa 2-wire serial interface. In addition, the entire family is available in 2.7V (2.7V to 5.5V)and 1.8V (1.8V to 5.5V) versions.

Parametrics

Absolute Maximum Ratings:(1)Operating Temperature:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage on Any Pinwith Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current:5.0 mA

Features

(1)Low-Voltage and Standard-Voltage Operation:2.7 (VCC = 2.7V to 5.5V);1.8 (VCC = 1.8V to 5.5V); (2)Low-Power Devices (ISB = 6 μA @ 5.5V) Available; (3)Internally Organized 4096 x 8, 8192 x 8; (4)Two-wire Serial Interface; (5)Schmitt Trigger, Filtered Inputs for Noise Suppression; (6)Bidirectional Data Transfer Protocol; (7)400 kHz (1.8V, 2.5V, 2.7V, 5V) Compatibility; (8)Write Protect Pin for Hardware Data Protection; (9)32-byte Page Write Mode (Partial Page Writes Allowed); (10)Self-timed Write Cycle (5 ms Max); (11)High Reliability:Endurance: 1 Million Write Cycles;Data Retention: 100 Years; (12)Automotive Devices Available; (13)8-lead JEDEC PDIP, 8-lead JEDEC SOIC, 8-lead EIAJ SOIC, 8-lead Mini-MAP (MLP 2x3)and 8-lead TSSOP Packages; (14)Lead-free/Halogen-free; (15)Die Sales: Wafer Form, Waffle Pack, and Bumped Wafers
